HF-151ES Hydraulic Riveting Machine
Hydraulic System Design
System Advantage
- It is specially designed to replace the traditional hand pressure table. This simplified machine can be moved according to the working environment. The hydraulic design can reduce the long-time work pressure.
- It is suitable for flat hardware accessories.
- Replacing the upper and lower molds and the working platform could be moved according the riveting needs.
- Easy operation and durable.
Handle Right or Left Swipe See More
| Stroke | mm | 70 |
| Throat depth | mm | 130 mm |
| Pressure | TONS | 1.5 Tons |
| Motor | HP | 2 HP |
| Operation | Hydraulic | |
| Machine size | mm | 700×650×1650 |
| N.W. | kgs | 315 |
- For more information,Please call for US.
- 886-4-25243647
